`.gfpd` plugins

GrooveForge Plugin Descriptor — one YAML file for metadata, signal graph, parameters, and UI layout.

Why it exists

Most built-in audio effects and all bundled MIDI FX are described declaratively. You can ship new plugins by writing YAML: no Flutter UI code and no recompile for experiments (you can also load a file from disk via Load .gfpd from file… in the add-plugin sheet).

Rack slots showing descriptor-based effect panels with rotary controls — Descriptor plugins appear as normal rack cards — auto-generated knobs and sliders from the `ui:` block in each `.gfpd` file.

Plugin types

`type:`	Use
`effect`	Stereo insert / send effect; `graph:` with `audio_in` / `audio_out` and DSP nodes.
`midi_fx` (or `midifx`)	MIDI processor; `midi_nodes:` chain (transpose, harmonize, arpeggiate, …).
`instrument` / `analyzer`	Reserved for advanced GFPA use cases — see API docs in the repo.

What goes in the file

spec: "1.0", unique id (reverse-DNS), name, version, type.
parameters: — automatable controls with stable paramId integers (never reuse IDs once shipped).
Audio: graph: with nodes and connections (Freeverb, delay, EQ, compressor, chorus, wah, …).
MIDI: midi_nodes: with node type and params bound to { param: id } or constants.
ui: — knobs, sliders, toggles, selectors, meters; optional groups: for responsive sectioning.

Authoring guide (repository)

The canonical reference is assets/plugins/HOW_TO_CREATE_A_PLUGIN.md — node catalogue, UI control types, recipes (wet/dry, BPM-synced wah), and a pre-publish checklist.

Download bundled `.gfpd` files (from `main`)

File	Kind
reverb.gfpd	Audio — plate reverb
delay.gfpd	Audio — ping-pong delay
wah.gfpd	Audio — auto-wah
eq.gfpd	Audio — 4-band EQ
compressor.gfpd	Audio — dynamics
chorus.gfpd	Audio — chorus / flanger
harmonizer.gfpd	MIDI FX
chord_expand.gfpd	MIDI FX
arpeggiator.gfpd	MIDI FX
transposer.gfpd	MIDI FX
velocity_curve.gfpd	MIDI FX
gate.gfpd	MIDI FX

← .gfdrum · Full feature list →
